Intel® x86 Architecture
JHCTECH's BRAV series are industrial Edge AI GPU computers, which are the perfect computing solutions for artificial intelligence(AI) enabled vehicles related applications such as Automated Guided Vehicles (AGV), Autonomous Driving Vehicles, ETC(Electronic Toll Collection) license plate recognition as well as for pure artificial intelligence(AI) computing applications, like image and video analysis, deep learning, machine vision, data mining, etc. JHCTECH's BRAV-embedded computers provide high-performance computing capacity with AI accelerator cards and huge storage space for Edge AI applications.
Intel® Tiger lake UP3 CPU, 3*LAN, 5*USB, 2*COM, 1*DIO, HDMI+DP, 2*M.2 support 4G LTE/5G NR，2*M.2 support edge AI module
BRAV-7220 is an AI MEC computing system with high energy efficiency ratio, powered by Intel® Tiger lake UP3 ULT SoC series CPU. 2.5G network port and 5G NR wireless network, support dual M.2 edge AI calculation module, no fan heat dissipation, DC 9-36V wide power input，can realize multilateral access, can be used as MEC edge computing for intelligent transportation and machine vision detection.
Intel® Skylake-S/Kabylake-S Core I3/I5/I7 CPU, 7*LAN, 6*USB3.0, MXM3.1 GPU
6*4K display, iVpro technology, DC-IN 6~48V
BRAV-7201 is a new industrial design scheme, aluminum moment profile box computer without fan heat dissipation. Intel Skylake- U/Kabylake-U CPU, dual DDR4 2133MHz SODIMM, up to 32GB。 Intel 9 gen HD Graphics, HDMI and DP dual 4K display, 5*G- LAN, 4*USB3.0, 6*COM, 16-bit Iso DIO, 1*Mini PCIe, support MLU220 M.2, support dual 4G/Wifi/BT. mSATA and 1*2.5 SATA HDD/SSD. High-reliability 9-30V wide power input， Aluminum profile bottom shell is designed for hard disk heat dissipation. It is widely used in artificial intelligence, machine vision and robotics.
Intel® Skylake-S/Kabylake-S Core I3/I5/I7 CPU, 7*LAN, 6*USB3.0, MXM3.1 GPU
6*4K display, iVpro technology, DC-IN 6~48V
BRAV-7302 is a high-performance GPU Box Computer, CPU and GPU fan cooling by independent air passage. It is powered by all kinds of Intel Skylake® -S/Kabylake-S CPU, DDR4 2133/2400MHz dual channel memory up to 32GB. DP1.2+HDMI1.4b dual 4K Intel HDG display, 3*DP+1*HDMI GPU display. 3/7*Intel LAN, 4/6*USB3.0, 2*Mini PCIe and 1*M.2 support 4G and Wifi/BT.The2*2.5"SATA HDD/SSD support Raid0/1.WithDC6-48V wide power input, high performance and multi IO, it is the application for Intelligent AI, Video Security and Machine Vision.
Intel® Coffee Lake LGA1151 CPU, 3*LAN, 4*USB3.1, 1*HDMI, 2*DP, 3*4K Displays,
4*PCIe slots, 4*SATA3, ATX 400W Power.
BRAV-7501 is a Workstation-grade Edge Computing system. It is powered by Intel® Coffee Lake-R series processor, Intel® Q370/C246 Chipset, 4*DDR4 2666/2400MHzdualchannelmemory, up to 128 GB, 2*DP1.2+1*HDMI 1.4 b. 3*GbE LAN, 4*USB3.1, 1*Mini PCIe supports 4G /WiFi/BT.1*M.2 M- Key,support NVMe.S001with2*3.5"SATA3bay,S002with4*2.5" SATA3 HDD/SSD tray, support RAID 0/1/5/10. support multiple PCIe expansion, flexible to meet application requirements. Workstation level system performance, rich expansion flexibility, industrial level product design which is very suitable for industrial automation, AI edge computing, small intelligent workstations, multimedia service systems, visual control and so on.
AI workstation.Intel® Coffee Lake-RLGA1151 CPU, Multi-channel memory, DC power supply, with Modular I/O Expansion Design, Support 350W GPU expansion.
BRAV-7520 is a Workstation-grade Edge Computing system. It is powered by Intel® CoffeeLake-Rseriesprocessor, Intel® Q370/C246Chipset,4*DDR4 2666/2400MHzdualchannel memory, up to 128GB，2*DP1.2+1*VGA. 3*GbE LAN, 6*USB3.1, 1*Mini PCIe supports 4G /WiFi/BT. 1*M.2 E-Key & SIM, 1*M..2 B-key, support 5G , 1*M.2M-Key,supportNVMe.2*2.5" SATA3 HDD/SSD tray, support RAID 0/1. support multiple PCIe expansion, flexible to meet application requirements. Workstation level system performance, rich expansion flexibility, industrial level product design which is very suitable for industrial automation, AI edge computing, small intelligent workstations, multimedia service systems, high-precision machine vision and so on.
Intel® Coffee Lake-RLGA1151 CPU, Dual-GPU, Multi-channel memory, DC power supply, with Modular I/O Expansion Design
BRAV-7521 is a Workstation-grade Edge Computing system. It is powered by Intel® Coffee Lake-R series processor, Intel® Q370/C246 Chipset, 4*DDR4 2666/2400MHzdualchannel memory, up to 128GB，2*DP1.2+1*VGA. 3*GbE LAN, 6*USB3.1, 1*Mini PCIe supports 4G /WiFi/BT. 1*M.2 E-Key & SIM, 1*M.2 B-key, support 5G, 1*M.2 M-Key, support NVMe.4*2.5" SATA3 HDD/SSD tray, support RAID 0/1/5/10. support multiple PCIe expansion, flexible to meet application requirements. Workstation level system performance, rich expansion flexibility, industrial level product design which is very suitable for industrial automation, AI edge computing, small intelligent workstations, multimedia service systems, high-precision machine vision and so on.
Intel® Comet lake 10th-Gen Celeron/Pentium/Core™ i9/i7/i5/i3 CPU,7*LAN, 8*USB, 2*COM, 3*M.2, 8+16 bit DIO
BRAV-7601 is a high-performance AI MEC computing system powered by Intel® Comet lake 10th-Gen CPU. Which is very suitable for C-V2X, Special vehicle mounted, high-precision machine vision, medical imaging and other applications.
Intel® Comet lake Celeron/Pentium/Core™ i9/i7/i5/i3 CPU, 3*LAN, 4*POE, 8*USB, 2*COM, 3*M.2, 24 bit DIO
BRAV-7601 is a high performance fan-less AI MEC computing system, powered by Intel® Comet lake CPU，network port multi-display and multi-IO functions, including 1 POE and 3 POE, DC9-36V wide voltage power supply with ACC delay power on/off function, suitable for vehicle-road collaboration C-V2X, special vehicle on-board, machine vision, medical imaging and other industry applications.
Intel® Alder lake-S/Raptor lake-S CPU, 3*LAN, 6*USB3.2, 8K DP+4K HDMI , PCIe5.0 X16+PCIe4.0 X4，2*2.5”SATA bay, 1000W PSU DC IN 12V.
BRAV-7720-S001 is a workstation-grade Edge computing system, powered by Intel® Alder Lake-S or Raptor lake-S series CPU, Q670 chipset, dual-channel DDR5 memory, and dual PCIe expansions. Flexible optional computing power, multi IO interfaces, high PFC power supply, high efficiency cooling solution and industrial grade reliability design, very suitable for V2X MEC, highway event detection, unmanned experiment vehicle and high-precision machine vision and other fields .
Intel® Alder Lake-S LGA1700 CPU, 3*LAN, 6*USB3.2, 8K DP+4K HDMI , PCIe5.0 X16+PCIe4.0 X4，2*2.5”SATA bay, 600W DC IN 9-55V.
BRAV-7720-WP is a workstation-grade Edge computing system, powered by Intel® Alder Lake-S series CPU, Q670 chipset, dual-channel DDR5 memory, and dual PCIe expansions. Flexible optional computing power, multi IO interfaces, high PFC power supply, high efficiency cooling solution and industrial grade reliability design, very suitable for V2X MEC, highway event detection, unmanned experiment vehicle and high-precision machine vision and other fields and applications.
Intel® Alder Lake-S LGA1700 CPU, 3*LAN, 6*USB3.2, 8K DP+4K HDMI , 2*PCIe5.0 X8+2*PCIe4.0 X4，2*2.5”SATA bay, 1000W DC IN 12V.
BRAV-7721-S001 is a workstation-grade Edge computing system, powered by Intel® Alder Lake-S series CPU, Q670 chipset, dual-channel DDR5 memory, and four PCIe expansions. Flexible optional computing power, multi IO interfaces, high PFC power supply , high efficiency cooling solution and industrial grade reliability design, very suitable for V2X MEC, highway event detection, unmanned experiment vehicle and high-precision machine vision and other fields and applications.
Intel® Alder Lake-S LGA1700 CPU, 3*LAN, 6*USB3.2, 8K DP+4K HDMI , 2*PCIe5.0 X8+2*PCIe4.0 X4，2*2.5”SATA bay, 1000W DC IN 9-55V.
BRAV-7721-WP is a workstation-grade Edge computing system, powered by Intel® Alder Lake-S series CPU, Q670 chipset, dual-channel DDR5 memory, and four PCIe expansions. Flexible optional computing power, multi IO interfaces, high PFC power supply, high efficiency cooling solution and industrial grade reliability design, very suitable for V2X MEC, highway event detection, unmanned experiment vehicle and high-precision machine vision and other fields and applications.
Intel® 12th/13th/14th Gen Core i9/i7/i5/i3/Pentium/Celeron CPU, 4*DDR5, 3*LAN, 4*USB3.2, 2*COM, 4*HDMI, 1*Mini PCIe, 2*M.2 ，1*2.5" SATA, 1*MXM slot, DC-IN 19V
BRAV-7722 is a high performance AI edge computing system equipped with Intel® Alder lake-S/Raptor lake-S/Raptor lake-S Refresh series processors with Q670 chipset. CPU+GPU dual processor high-performance multi-network port multi-display multi-IO function, optional support BMC module to achieve remote management, DC 19V DC power supply interface, used in intelligent transportation, machine vision, unmanned driving, intelligent security, digital medical and other fields.
Intel Core Ultra CPU, 2*LAN, 4*USB Type-A, 2*HDMI, 2*COM, 2*M.2 M-key, 1*M.2 B-key, 1*M.2 E-key. DC-IN 12V
The BRAV-7820 is equipped with an Intel® Core™ Ultra processor, supporting up to 96GB of RAM. It features multi-network, multi-display, multi-storage, and multi-expansion capabilities, powered by DC 12V/10A input. Designed for MEC (Multi-access Edge Computing) edge computing, it is ideal for industries such as smart transportation, machine vision, and intelligent logistics.
