SCC-3116|Fanless Box Computer

SCC-3116|Fanless Box Computer

Intel® Celeron J1900 CPU, 2/3*LAN, 7*USB, 6*COM, 1*HDMI+1*VGA, Dual display, Optional 8-bit DIO, CPU temp. show in LED, DC IN 9~36V.

SCC-3116 is a multi-IO industrial design Box Computer of JHCTECH with an aluminum chassis and fanless design. It is powered by Intel® Baytrail Celeron J1900 2.0-2.42 CPU and DDR3L 1333MHz memory, up to 8GB. HDMI and VGA dual independent display, 2/3*Gig. LAN, Integrated 10/100/1000M. 6*COM, 7*USB, optional 8-bit DIO, 1*Mini PCIe which support 4G and Wifi/BT. 1*2.5" SATA HDD/SSD, 1*mSATA, Dual storage. With DC 9~36V wide power input. Operating temperature showing in LED, it will be fit for IoT terminal, automation and manufacture application.
2 years warranty


1.Color:Silver & Grey

2.Net weight:TBD

3.Mounting:Desktop Mounting


5.Operating temperature:

-20°C~65°C – Fanless with wide operating temp. SSD, Airflow

-10°C~55°C – Fanless with HDD, Airflow

6.Storage temperature:-40°C~85°C

7.Storage Humidity:10~90%@40°C, Non-condensing


5 grms/5~500Hz/ random/in working(SSD);
1 grms/5~500Hz/random/in working(HDD)


50g peak acceleration(11ms duration)(SSD);
20g peak acceleration(11ms duration)(HDD)

10.Certification/EMC:CE/FCC Class A

11.Structure:aluminum chassis, SGCC frame

[Key features]

-Aluminum chassis, fanless design

-Intel® Baytrail Celeron J1900 2.0-2.42 CPU

-1*DDR3L 1333MHz SODIMM, Up to 8GB

-1*HDMI, 1*VGA, Dual independent display

-2/3*Gig LAN, 1*USB3.0, 6*USB2.0(one inside)

-6*COM, Optional 8-bit DIO, 1*Audio out, 1*MIC

-1*Mini-PCIe(PCIeX1+USB), 1*PS/2

-1*F-mSATA, 1*2.5" SATA HDD/SSD driver

-DC 9~36V Wide Power Input



Iot terminal, automation and manufacture application.


CE/FCC Class A
